Construction Compactor Rentals

Ellis Equipment carries jumping jacks, compaction wheels, vibratory plate compactors and walk behind sheep’s foot rollers. So, whether you’re doing earthwork, trench and sewer line construction, backfills or foundation work, we have you covered. When high demands are placed on mobility, maneuverability and simple operation under severe soil conditions, we have the right compactor for your application.

For all compaction wheels, if you do not see your machine listed below please let us know. Please have the following information ready:

  • Pin Sizes in MM or INCHES

  • Pin centers in MM or INCHES

  • Distance between the ears.



Backhoe Wheels



Small Backhoe Wheels

10,500 - 17,500 LBs Machine Class

Models: DC-18 S
Width: 17"
Rim Diameter: 32"
Rims: 3
Approx. Weight: 1050 LBs

Large Backhoe Wheels

10,500 - 17,500 LBs Machine Class

Model: DC-24 S
Width: 22"
Rim Diameter: 32"
Rims: 3
Approx. Weight: 1150 LBs



Excavator Wheels



Excavator Wheels

27,500 - 50,000 LBs Machine Class

Models: DC-24 BL
Width: 23"
Rim Diameter: 38"
Rims: 3
Approx. Weight: 2450 LBs
Fits: JD200, JD280, Cat320



Mini Excavator Wheels



Mini Excavator Wheels

3,500 - 10,500 LBs Machine Class

Models: DC-16 SKH
Width: 16"
Rim Diameter: 22"
Rims: 3
Approx. Weight: 500 LBs
Fits: 1/8yd W/R, 1/8yd CP, TB135, JD27D



Jumping Jacks



Jumping Jacks

Our Jumping Jacks are great for tight areas where working space is limited.

Model: BT80D
Working Width: 330mm
Performance KW: 3.1 Yanmar
Operating Weight: (kg) 81
Fuel Type: Gasoline and Diesel Available

(All units come with chain and CAT padlock)



Remote Walk Behinds



Walk Behind Sheepsfoot

Ideal for base preparation, compaction and back filling around footings and foundations, backfilling of trenches, and compaction of difficult soils where high maneuverability is required.

Drum width: 24" or 33"

• Remote operation

• Articulating

• Sheepsfoot ONLY



Single Directional Compactors



BOMAG BVP 18/45

Ideal for compaction of a wide variety of sand, gravel and granular base materials, and hot and cold asphalt patching.

Working width inch (mm): 4517.7 (450)
Performance hp (kw): 4.8 (3.6) Honda
Operating weight lbs (kg): 198 - 201 (90 - 91)



Vibratory Compactor Plates



Model: BTI TC90S

Minimum Carrier Size: 7,700lbs
Maximum Carrier Size: 25,300
Operating Rate: 1,130lbs
Impulse Force @ min. RPM: 5,500lbs
Impulse Force @ max RPM: 8,200lbs
Min Flow Rate: 20.6 US Gallons per minute
Max Flow Rate: 25.2 US Gallons per minute
Width: 23” to fit in a 24” Trench
